DEKTEC 德克泰可 DTU-315 All Standard all Band Modulator 信號調變器
DEKTEC
DTU-315
All Standard all Band Modulator for USB 3.0
信號調變器
DTU-315
All Standard all Band Modulator for USB 3.0
信號調變器
DEKTEC DTU-315 All Standard all Band Modulator 信號調變器 USB 3.0
Modulation has never been so easy and so beautiful. The DTU-315 is a portable modulator for satellite, terrestrial and cable, all in a single device.
A good fit for laptop or tablet, but convenient with desktops and server PCs too.
| RF frequency | VHF, UHF, L band 36 to 2150MHz |
| Mod. bandwidth | Up to 70MHz |
| RF output level | -45 to -25dBm |
| RF out | 75-Ω micro-BNC female |
| USB | USB 3.2 Gen 1, micro-B
Also called SuperSpeed USB |
| Power | USB powered
No separate power supply required |
| Standards included with base product | ATSC 8VSB DVB-C DVB-CID DVB-S, DVB-S2 DVB-T, DVB-T2 single PLP QAM-B, QAM-C |
| Options | ATSC-M/H ATSC 3.0 CMMB DAB(+), DRM(+), T-DMB DTMB (ADTB-T, DMB-T/H) DVB-C2 DVB-S2X DVB-T2 multi PLP ISDB-S, ISDB-S3 ISDB-T, ISDB-Tmm |
| More options | I/Q sample playout AWGN insertion Multipath echo simulation Remotely controlled playout |
| GOLD option | All options in this table, plus all future modulation options developed for the DTU-315 |
